Hamburger Meat Patty Stacker
Our Patty Stacker automatically takes patties from the freezer belt and stacks them, greatly improving efficiency and reducing labor costs.
- henco
- China
- 30days
- 10000
- Information
Patty Stacker, crafted with stainless steel and food-grade engineering plastics, stacks frozen, formed products automatically, including burger patties, fish patties, vegetable patties, pork chops, cookies, and potato pancakes. The patties are positioned one behind the other, ensuring quick loading into packaging boxes. With customization options based on the actual requirements such as shape, size, and production capacity, the automatic stacker can be tailor-made, offering a versatile solution for your stacking needs.
Advantages:
l To stack the patties from IQF
l Famous brand electrical parts.
l Grade of waterproof: IP55
l Stainless steel made and
l portion non-metal material, safe and reliable
l Smooth and bright laser cutting
l No sanitary dead spots.
Technical data:
4 Through | Data | Remarks |
Infeed belt width | 703 mm |
|
Power | 415V 50Hz 3P | Customizable |
Motor | SEW |
|
Through | 4 |
|
Patty size | See bellow table | Customer request |
Capacity | 450pcs / min |
|
Dimension | L 2395mm x W 1355mm x H 891mm±150mm |
Options:
- Bagging Tool
l Stainless steel made, safe and reliable
l Smooth and bright laser cutting
Business Conditions
(1). 30% of total amount need be paid by T/T as down payment, rest need be paid by T/T before delivery.
(2). The delivery time is 30 working days after received the down payment.
Technical Documents
1. Instructions for use
2. Certificate of conformity
3. Packing list (including accessories)
Technical Training
The company is responsible for free debugging of users and operator training. Make the operator familiar with the operation procedures according to the product instructions, routine maintenance, to ensure the normal operation of the equipment.
Training Programs and plans:
Training location: equipment manufacturing site and equipment installation site;
